Cisco Meraki offers a broad range of switches built from the ground up that are designed to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.
Meraki access and aggregation switches are all managed through an elegant, intuitive cloud interface, freeing administrators to spend less time on configuration and more time on meeting business needs.
To set up a Meraki switch, just plug it in; there's no need for repetitive, commandbased configuration. Switches can be up and running within minutes of connecting them to the network.
A powerful centralized management interface gives administrators deep visibility into the network and how it is used. See which switches are near capacity across hundreds of sites. Quickly provision and reconfigure switch ports with security, quality of service (QoS), and more. The Meraki dashboard provides unified policies, event logs, and monitoring, making switch management efficient and scalable.
General Information
| Product Type |
Ethernet Switch |
| Manufacturer Part Number |
MS1308HW |
| Manufacturer Website Address |
http://www.cisco.com/c/en_au |
| Manufacturer |
Cisco Systems, Inc |
| Product Model |
MS130-8-HW |
| Product Name |
MS130-8-HW Ethernet Switch |
| Product Series |
MS |
| Brand Name |
Meraki |
Management & Protocols
Miscellaneous
| Application/Usage |
VoIP Phone |
| Office |
| Campus |
| Business |
| Package Contents |
MS130-8-HW Ethernet Switch Power Supply Getting Started Insert |
Network & Communication
| Layer Supported |
2 |
| Networking Standards |
IEEE 802.1Q |
| IEEE 802.1x |
Physical Characteristics
| Form Factor |
Rack-mountable |
I/O Expansions
| Expansion Slot Type |
SFP |
| Number of SFP Slots |
2 |
| Total Number of Expansion Slots |
2.0 |
Interfaces/Ports
| Network (RJ-45) |
Yes |
| Uplink Port |
Yes |
| Stack Port |
Yes |
| Total Number of Network Ports |
8 |
| Port/Expansion Slot Details |
2 x Gigabit Ethernet Expansion Slot |
| 8 x Gigabit Ethernet PoE+ |
Media & Performance
| Network Technology |
1000Base-X |
| 10/100/1000Base-T |
| Ethernet Technology |
Gigabit Ethernet |
| Media Type Supported |
Twisted Pair |
| Optical Fiber |
Power Description
| Power Source |
Power Supply |
| PoE (RJ-45) Port |
Yes |
| Redundant Power Supply Supported |
Yes |
