The Intel S4510 Entry SATA solid-state drives (SSDs) for Lenovo servers use Intel 64-layer 3D NAND TLC Flash Memory technology with a 6Gbps SATA interface to provide an affordable solution with industry leading performance. Compared with the Intel S4500 series, these new drives offer improved performance and significantly improved endurance. The S4510 SSDs are optimized for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
Drive Performance
| Maximum Read Transfer Rate |
560 MB/s |
| Maximum Write Transfer Rate |
290 MB/s |
| Endurance (DWPD) |
2.1 |
| Endurance (TBW) |
900 TB |
| Endurance Type |
Read Intensive |
Interfaces/Ports
| Drive Interface |
SATA |
| Drive Interface Standard |
SATA/600 |
Miscellaneous
| Compatibility |
Levono SD650 (7X58) Server |
| Device Supported |
Server |
| Environmentally Friendly |
Yes |
Network & Communication
General Information
| Product Type |
Solid State Drive |
| Manufacturer Part Number |
4XB7A13666 |
| Manufacturer Website Address |
http://www3.lenovo.com/au/en |
| Manufacturer |
Lenovo Group Limited |
| Product Name |
ThinkSystem SD650 2.5" Intel S4510 240GB Entry SATA Hot Swap SSD |
| Product Series |
D3-S4510 |
| Brand Name |
Lenovo |
Physical Characteristics
| Hot Swappable |
Yes |
| Drive Type |
Internal |
| Form Factor |
2.5" |
Power Description
| Operating Power Consumption |
2.40 W |
Technical Information
| Storage Capacity |
240 GB |
| Encryption Standard |
256-bit |
