Accommodate the active TV positioning needs of today and tomorrow. Lift, swing or turn your display in any direction! Features 20 inches (51 cm) of vertical adjustment and 20.75-inch (53 cm) motion adjustment to either side.
Now anyone can effortlessly move their TV into multiple positions with only a light touch. Your screen will seemingly float on air, being easily adjusted between standing and seated heights. No more awkward viewing angles and sore necks.
General Information
Physical Characteristics
| Product Color |
Polished Aluminum |
| Black |
| VESA Mount Compatible |
Yes |
| Mounting Pattern |
200 x 100 |
| 200 x 400 |
| Product Material |
Aluminium |
| Height |
35.6 cm |
| Width |
72.6 cm |
Miscellaneous
| Additional Information |
- Patented Constant Force technology enables light-touch adjustments
- Gravity pivot enables tilting capabilities without the need of knobs or levers
- Tilts forward 15°, tilts back 5°
- Rotation of +/-5° provides leveling adjustment of screen in any position
- Level the screen at any position with +/- 5º of post-installation rotation
- Provides smooth, continuous vertical and horizontal movement of the TV/display in all directions
- Extends 28" (71 cm) from wall when in use and can be fully retracted to 6.5" (17 cm) when not in use
|
| Compatibility |
Product Information
| Device Supported |
Flat Panel Display |
| Minimum Load Capacity |
15.88 kg |
| Maximum Load Capacity |
31.75 kg |
| Minimum Screen Size Supported |
76.2 cm |
| Maximum Screen Size Supported |
152.4 cm (60") |
| Maximum Adjustable Height |
50.8 cm |
| Features |
Pivot |
| Tilt |
| Pan |
| Rotate |
| Heavy Duty |
| Leveling System |
| Cable Management |
| Adjustable Width |
| Height Adjustable |
Yes |
