The Lenovo ThinkSystem PM883 Entry SATA 6Gb solid-state drives (SSDs) in capacities ranging from 240 GB to 7.86 TB are general-purpose SSDs based on the Samsung PM883 platform. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.
Drive Performance
| Maximum Read Transfer Rate |
550 MB/s |
| Maximum Write Transfer Rate |
520 MB/s |
| Endurance (DWPD) |
0.8 |
| Endurance (TBW) |
1366 TB |
| Endurance Type |
Read Intensive |
General Information
| Manufacturer |
Lenovo Group Limited |
| Manufacturer Part Number |
4XB7A17178 |
| Manufacturer Website Address |
http://www3.lenovo.com/au/en |
| Brand Name |
Lenovo |
| Product Series |
PM883 |
| Product Name |
ThinkSystem 3.5" PM883 960GB Entry SATA 6Gb Hot Swap SSD |
| Packaged Quantity |
1 |
| Product Type |
Solid State Drive |
Interfaces/Ports
| Drive Interface |
SATA |
| Drive Interface Standard |
SATA/600 |
Power Description
| Operating Power Consumption |
3.10 W |
Miscellaneous
| Package Contents |
ThinkSystem 3.5" PM883 960GB Entry SATA 6Gb Hot Swap SSD |
| 2.5-inch-to-3.5-inch Conversion Tray |
| Documentation Flyer |
| Compatibility |
ThinkSystem server support: - ST550 (7X09/7X10)
- SR530 (7X07/7X08)
- SR550 (7X03/7X04)
- SR570 (7Y02/7Y03)
- SR590 (7X98/7X99)
- SR630 (7X01/7X02)
- SR650 (7X05/7X06)
|
| Device Supported |
Server |
Network & Communication
Physical Characteristics
| Drive Type |
Internal |
| Form Factor |
2.5" |
| Drive Carrier |
Yes |
| Drive Carrier Width |
3.5" |
| Hot Swappable |
Yes |
| Height |
7 mm |
| Width |
70 mm |
| Depth |
100 mm |
| Weight (Approximate) |
58 g |
