The Intel S4510 Entry SATA solid-state drives (SSDs) for Lenovo servers use Intel 64-layer 3D NAND TLC Flash Memory technology with a 6Gbps SATA interface to provide an affordable solution with industry leading performance. Compared with the Intel S4500 series, these new drives offer improved performance and significantly improved endurance. The S4510 SSDs are optimized for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
Drive Performance
| Maximum Read Transfer Rate |
560 MB/s |
| Maximum Write Transfer Rate |
510 MB/s |
| Random 4KB Read |
95000IOPS |
| Random 4KB Write |
36000IOPS |
| Endurance (DWPD) |
1.9 |
| Endurance (TBW) |
3481.60 TB |
| Endurance Type |
Read Intensive |
Miscellaneous
| Compatibility |
Levono Servers:
- ST550 (7X09/7X10)
- SR530 (7X07/7X08)
- SR550 (7X03/7X04)
- SR570 (7Y02/7Y03)
- SR590 (7X98/7X99)
- SR630 (7X01/7X02)
- SR650 (7X05/7X06)
- SR850 (7X18/7X19)
- SR860 (7X69/7X70)
- SR950 (7X11/12/13)
- SD530 (7X21)
- SN550 (7X16)
- SN850 (7X15)
|
| Environmentally Friendly |
Yes |
| Device Supported |
Server |
Network & Communication
Technical Information
| Storage Capacity |
960 GB |
| Encryption Standard |
256-bit |
General Information
| Manufacturer |
Lenovo Group Limited |
| Manufacturer Part Number |
4XB7A10249 |
| Manufacturer Website Address |
http://www3.lenovo.com/au/en |
| Brand Name |
Lenovo |
| Product Series |
D3-S4510 |
| Product Name |
ThinkSystem 2.5" Intel S4510 960GB Entry SATA 6Gb Hot Swap SSD |
| Product Type |
Solid State Drive |
Interfaces/Ports
| Drive Interface |
SATA |
| Drive Interface Standard |
SATA/600 |
Physical Characteristics
| Drive Type |
Internal |
| Form Factor |
2.5" |
| Drive Carrier |
Yes |
| Hot Swappable |
Yes |
Power Description
| Operating Power Consumption |
2.70 W |
